Interactive LightSAFE
Configurator

Call or email us

Questions about your enclosure or current pricing? We’re here to help.

Call: 714-680-6211
Email: info@serralaser.com

SIMULATION button

SIMULATION is next to GUIDE above the 3D preview. Press it and the configurator cycles through choices you can make while designing a LightSAFE — size, doors, windows, layouts, ceiling, daisy-chain, tables, LightSHELF, and more. When the simulation finishes it returns to the opening screen. To stop the tour at any time, press Start Over. The simulation ends and you go back to the opening setup.

View Inside button

View Inside puts you inside the LightSAFE so you can see the layout from the welder’s point of reference. It works best on a single LightSAFE (one room). Use it after you place doors, windows, tables, and LightSHELFs to check clearances and sight lines.

Setting the size

Use Length, Width, and Height in the left column. Sizes use modular 2 ft and 4 ft panels. Type a value or drag the sliders — the enclosure snaps in 2 ft steps. Height buttons set 8, 10, or 12 ft walls. The 3D preview and price update as you change size.

Adding doors

Every LightSAFE includes one standard 48" sliding door with a viewing window. Under DOORS & LOCATIONS use Add Door for extras. Pick size (48", 6 ft, or 8 ft), then choose Door Location by numbered panel. Doors are manual sliding doors — they are not automatic.

Door open direction

Under each door, Left / Right sets which way the leaf slides along the wall. A direction is disabled if that slide would run off the end of the wall. You can also open and close doors in the 3D preview with the door toggle.

Adding windows

Open the Windows tab to manage wall windows and door viewing windows. Click Add Window, choose 12×24, 24×24, 24×36, or 36×44, and pick a numbered panel that is not already a door. 2 ft panels only take windows up to 24" wide. Use Label Panels so the panel numbers match the 3D view and the top-down floor plan.

Adjusting height

Height is in the left-hand column with Length and Width. Use the 8 / 10 / 12 ft Height buttons. Taller walls add height-extension cost on the estimate automatically.

Adding a ceiling

ADD CEILING & LIGHTS is available in the Room section, below Height. Press the button to add a ceiling with LED lights and an exhaust fan. The ceiling cost is entered automatically in Cost Estimation when the option is on.

Layouts: 2-wall, 3-wall, 4-wall

LAYOUT CONFIGURATION is in the left-hand column. 4-wall is a standalone island. 3-wall sits against an existing building wall (no back). 2-wall is a corner (Front + Left or Front + Right). Daisy Chain is the fourth layout button in that same left-hand group.

Setting up Daisy-chain

Daisy-chain is selected in the left-hand column — the Daisy Chain layout button under Layout Configuration, plus the Daisy-chain extra rooms controls. Rooms must be large enough (minimum 8 ft × 16 ft). Choose split left/right or front/back. Use + / − or the slider under Daisy-chain walls to add dividers. Each room gets a door with a viewing window. Drag numbered dividers on the floor plan or in 3D. Divider Lock freezes them in place.

LightSHELF and welding tables

Add weld tables and LightSHELFs with the controls above the 3D preview, or the matching controls under the top-down floor layout. Next to those selectors you can target one room or Add All rooms. That lets you put a table or shelf in an individual daisy-chain room, or add one to every room at once. + adds another unit in the selected target; − or Clear removes them. Selected welding tables are included in your estimate and quote at the prices shown in the Siegmund section. The 2 × 3 ft option includes the 27-piece bundle; the 3D preview shows the table. Shipping not included.

Rotating tables and drag-and-drop

Drag a table or LightSHELF on the floor plan or in the 3D preview to move it. Use the rotate control on a welding table to turn it 90°. Scroll to zoom and drag empty space to orbit the 3D view.

Label Panels

Label Panels is the button above the 3D preview. Turn it on to show numbered modules on the enclosure. Those same numbers appear on the top-down floor layout. Use them to place doors and windows quickly and to match a 3D panel to the floor plan.

Adding LightWELD

In the pricing column open the LightWELD package. Quantities start at zero. Select a model such as LightWELD 1500 XR and set qty to 1. Optional wire feeders appear with the welder. The list updates the quote immediately.

Adding LightBOT

Open the LightBOT package and pick a robot such as LightBOT 10iAL. Set quantity, then add options if needed. Select a model and a quantity of at least one to qualify for the bundle discount. Options alone do not qualify.

5% bundle discount

The 5% bundle discount applies to the LightSAFE enclosure and to the LightWELD and/or LightBOT system on the same quote. Select at least one LightWELD or LightBOT model with a quantity of one or more. Checking a package box or adding only accessories does not qualify. Removing the last qualifying machine removes the discount. The price breakdown shows 5% off LightSAFE plus the welder and/or robot at bundle price next to list price.

Resetting

Start Over restores the first-load 12×12×8 four-wall room and clears doors extras, windows, daisy-chain, packages, colors, and accessories. Confirm the prompt. Use Back beside Start Over to undo the reset or your previous design change during this session.

Saving a configuration

Use Save in the header or configuration tools. Name the setup and save it in this browser, or download a JSON file. The name appears as the current configuration label so you can tell drafts apart.

Update button

Update saves the current LightSAFE back over the named version you are working on. The name does not change. After you Save Configuration once and give it a name, press Update as you go so that version stays current without creating a new name each time.

Printing, downloading, or requesting a quote

Request Quote opens the customer form with your current configuration. Download Quote saves a PDF, Print Quote opens a printable numbered quote, and Request Quote sends your design to Serra Laser. The quote includes your contact details, selected configuration, and estimated total. Selected tables are included with their part numbers, quantities and current catalog prices. Shipping not included. If online sending fails, your details stay in the form; download the quote and email it to info@serralaser.com.

Loading a configuration that was sent

Open the share link in a browser — the configurator reads the URL and rebuilds the enclosure. You can also use Load and pick a downloaded JSON file. After it loads, review doors, windows, and price before sending a quote.

Build sheet

Print / Build Sheet captures the 3D view and floor plan plus the configuration list and price. Selected welding tables show their part numbers, quantities and prices. Shipping not included. Door rows note that doors are not automatic.

Wood crate charge

Every configuration includes a standard WOOD CRATE charge of $750 in the estimated total. Crating charges may vary for custom enclosure configurations.

Hardware and installation manual

Every LightSAFE includes all hardware for wall and door construction, plus an installation manual written for the enclosure you are buying.

Modular — add on later

LightSAFEs are modular. They can be added to or reconfigured at any time as the laser welding area grows — add doors, make the room bigger, or convert to a daisy-chain layout.

Class 4 placards and testing

LightSAFE rooms include Class 4 placards as required by ANSI Z136.1 for the safe use of lasers. They have been tested with LightWELD handheld and robot-controlled laser welders.
